Multifunzioni e stampanti UTAX

UTAX P-6034DN

[P-6034DN]

Stampa Laser B/N

Specifiche Tecniche

general

Desktop
print
Laser b/w
max A4
256
1 x 500 sheet 1 x 500 sheet
A5R-A4
100 sheet multi-bypass (A6R-A3)
A6R-A4, 216 × 356 mm -70 × 139.7 mm banner: 915 mm length
500 sheet A4
1,200 x 1,200 dpi
USB direct printing PDF direct printing printing of e-mails private printing quiet mode (half speed mode) barcode printing banner print (max 915 mm) from multi-bypass Mobile Print (Android, iOS)/Apple AirPrint Google Cloud Print Wi-Fi Direct®
USB 2.0 10/100/1000BaseTX USB host (2) SD-Card Slot
PCL6 (PCL 5e, XL) KPDL 3 (PostScript 3 compatible) PRESCRIBE Ile Line Printer IBM Proprinter Epson LQ-850 XPS Open XPS PDF 1.7
TCP/IP Net BEUI
Windows 8 Windows 8.1 Windows 10 Server 2012 Server 2012 R2 Server 2016 Server 2019 Linux Mac ex OS 10.9
60.0 b/w-pages/min.
43.0 b/w-pages/min.
4.5 seconds
60.0 g/m²
120.0 g/m²
60.0 g/m²
220.0 g/m²
60.0 g/m²
120.0 g/m²
60.0 g/m²
220.0 g/m²
0.5 GB
2.5 GB

scanSystem

printSystem

Mobile Print (Android/iOS) Apple AirPrint Mopria

faxSystem

dimensionsWeight

363.0 mm
410.0 mm
416.0 mm

environment

56.2 dB(A)
27.4 dB(A)
220/240 V
GS/TÜV CE
50/60 Hz
710.2 W
1258.0 W
0.79 kwh/week
9.0 W
0.5 W

optional

Data security kit (E) Data security kit (E) Card authentication kit (B) UG-33 ThinPrint® kit IB-50 Gigabit Ethernet card cabinet no. 79 (high) cabinet no. 80 (low) caster kit CA-3100 HD-18 SSD (256 GB) HD-17 SSD (64 GB) HD-19 SSD (512 GB) IB-37 WLAN card (IEEE802.11a/b/g/n/ac) IB-38 W-LAN card**** (IEEE802.11 b/g/n Wi-Fi direct)
max 4 x PF-3110 (500 sheet universal cassettes [A5R-A4, 60-120 g/m²]) max 1 x PF-3100 (2,000 sheet large capacity tray [A5R-A4, 60-220g/m²]) PB-325 (Attachment Kit is required for PF-3100)
