UTAX P-3522DW

[P-3522DW]

Stampa Laser B/N

Specifiche Tecniche Brochures Manuali Immagini Driver Certificati Utilities

Specifiche Tecniche

general

Type Desktop

Function print

Print technology Laser b/w

Print format max A4

Greyscales 256

Paper feed (Universal cassettes amount) 1 x 250 sheet

Paper feed (1st cassette types) A6R-A4

Paper feed (Multi-Bypass amount) 100 sheet multi-bypass (A6R-A3)

Paper feed (Multi-Bypass types) A6R-A4

Paper output 250 sheet A4

Printing resolution (min) 600 x 600 dpi

Printing resolution (max) 1,200 x 1,200 dpi

Functions PDF direct printing printing of e-mails quiet mode (half speed mode) barcode printing Mobile Print (Android/iOS) Google Cloud Print Wi-Fi Direct®

Processor Cortex-A9, 800 MHz

Interfaces USB 2.0 10/100/1000BaseTX USB host SD-Card Slot Wi-Fi

Emulations PCL6 (PCL 5e, XL) KPDL 3 (PostScript 3 compatible) PRESCRIBE Ile Line Printer IBM Proprinter Epson LQ-850 PDF 1.7 XPS Open XPS

Network protocols TCP/IP Net BEUI

Operating systems Windows XP Windows Vista Windows 7 Windows 8 Windows 8.1 Windows 10 Server 2008 R2 Server 2012 R2 Server 2016 Linux Mac ex OS 10.5 Mac ex OS 10.5

Print speed (A4, Simplex) B/W 35.0 b/w-pages/min.

Print speed (A4, Duplex) B/W 17.5 b/w-pages/min.

1st page (printing, b/w) 6.8 seconds

Paper weights (Universal cassette min) 60.0 g/m²

Paper weights (Universal cassette max) 163.0 g/m²

Paper weights (Multi-Bypass min) 60.0 g/m²

Paper weights (Multi-Bypass max) 220.0 g/m²

Paper weights (Duplex min) 60.0 g/m²

Paper weights (Duplex max) 163.0 g/m²

System memory (RAM) 0.256 GB

System memory (RAM max) 0.256 GB

scanSystem

printSystem

faxSystem

dimensionsWeight

Dimensions (height) 272.0 mm

Dimensions (width) 375.0 mm

Dimensions (depth) 393.0 mm

environment

Noise level (busy, b/w) 47.9 dB(A)

Noise level (busy, colour) 47.9 dB(A)

Mains voltage 220/240 V

Safety GS/TÜV CE

Utility frequency 50/60 Hz

Power consumption (busy) 620.0 W

Power consumption (max) 966.0 W

Power consumption (TEC) 1.36 kwh/week

Power consumption (standby) 8.0 W

Power consumption (sleep) 0.8 W

optional

Other options UG-33 ThinPrint® kit cabinet no. 78

Paper feed max 2 x PF-1100 (250 sheet universal cassettes [A6R-A4, 60-163 g/m²])

Brochures

Datasheet English

DB_UT_P-3522DW_UK.pdf
Datasheet English

Product overview English 05/2025

EN_Product_overview_A4_A3_UT_05_2025_Rev_1.pdf
Product overview English 05/2025

Product Overview English 05/2023

EN_BC_PU_A4_UT_05_2023_Rev_1.pdf
Product Overview English 05/2023

Product Overview Italian 05/2023

IT_BC_PU_A4_UT_05_2023_Rev_1.pdf
Product Overview Italian 05/2023

Product overview Italian 05/2025

IT_Product_overview_A4_A3_UT_05_2025_Rev_1.pdf
Product overview Italian 05/2025

Datasheet Italian

DB_UT_P-3522DW_IT.pdf
Datasheet Italian

Manuali

Instruction Handbook English

IH_P-3522DW_UT_UK.pdf
Instruction Handbook English

Safety Guide (English, French, German, Italian, Spanish, Russian, Arabian)

EN_IH_Safety Guide_TA_UT_Rev_1.pdf
Safety Guide (English, French, German, Italian, Spanish, Russian, Arabian)

Instruction Handbook Italian

IH_P-3522DW_UT_IT.pdf
Instruction Handbook Italian

Immagini

Certificato

EU Declaration of Conformity RoHS German / English

CONF_RoHS_P-3522DW_UT_D_UK.pdf
EU Declaration of Conformity RoHS German / English

TUEV-Certificate

DE_EN_TUEV_P-3522DW_4020DN_4020DW_Rev_2.pdf
TUEV-Certificate

Safety data sheet Toner english

EN_EV__P-3522DW_P-3521MFP_P-3527wMFP_TO_TA_UT_Rev_3.pdf
Safety data sheet Toner english

EU Declaration of Conformity German / English

DE_EN_CONF_P-4020DW_P-3522DW_TA_UT_Rev_6.pdf
EU Declaration of Conformity German / English

EU Declaration of Conformity Battery German / English

DE_EN_EU-Konformitaetserklaerung_Batterie_P-3522DW_P-4020DN_P-4020DW_TA_UT_Rev_1.pdf
EU Declaration of Conformity Battery German / English

Environmental data sheet System Deutsch / English

DE_EN_SDS_P-3522DW_TA_UT_Rev_4.pdf
Environmental data sheet System Deutsch / English

Drivers

macOS Print Driver

Mac62_2026.07.03.dmg
macOS Print Driver

PCL5 Driver

PCL5_UniDriver_V310_cCD_cLP_20170703.zip
PCL5 Driver

PCL6 Driver

PCL6_UniDriver_V310_cCD_cLP_20170630.zip
PCL6 Driver

KX Universal Print PCL - Post Script Driver

Kx87_UPD_8.7A.0422.zip
KX Universal Print PCL - Post Script Driver

Linux Driver

LinuxDriver_V94_20240521.tar.gz
Linux Driver

KX XPS Universal Print Driver (KXv4)

Kxv4_v6.1.1603_TA_RC7_WHQL.zip
KX XPS Universal Print Driver (KXv4)

PRINT-DRIVER Windows 7, Windows 8, Windows 8.1, Windows 10, Server 2008, Server 2008 R2, Server 2012, Server 2012 R2, Server 2016

WinUSB-Driver_P-3521MFP_...P-4020DW_20170418.zip
PRINT-DRIVER Windows 7, Windows 8, Windows 8.1, Windows 10, Server 2008, Server 2008 R2, Server 2012, Server 2012 R2, Server 2016

Utilities

Network Device Manager

DM.4.0.1608.0.TA.InstallerStdv4.0.1209.zip
Network Device Manager

Firmware Upgrade Tool 64 Bit für Windows 10 // Windows 11 // Server 2016 // Server 2019 // Server 2022

SoftwareUpgradeTool_2.3.8.windows_x64.zip
Firmware Upgrade Tool 64 Bit für Windows 10 // Windows 11 // Server 2016 // Server 2019 // Server 2022

Firmware Upgrade - P-3522DW

FW_P-3522DW_v2.12.fwp
Firmware Upgrade - P-3522DW

Network Device Manager - UserGuide

Device_Manager_UserGuide_TA.zip
Network Device Manager - UserGuide

Device Manager Installation Guide

Device_Manager_4.0_Installation Guides_TA.All_lang.zip
Device Manager Installation Guide

Network Print Monitor

Network Print Monitor_6.13.0902.zip
Network Print Monitor

Multiset Template Editor

MultiSetTemplateEditor.mste.4.6.0727.zip
Multiset Template Editor

Firmware Upgrade Tool für Mac OS 12 Monterey // Mac OS 13 Ventura // Mac OS 14 Sonoma // Mac OS 15 Sequoia // Mac OS 26 Tahoe

SoftwareUpgradeTool_2.3.8.macos.zip
Firmware Upgrade Tool für Mac OS 12 Monterey // Mac OS 13 Ventura // Mac OS 14 Sonoma // Mac OS 15 Sequoia // Mac OS 26 Tahoe

Network Utility WiFi Setup Tool

NW_WiFi_Setup_Tool_20190222.zip
Network Utility WiFi Setup Tool
