UTAX 5059i

[5059i]

Copia, stampa, scansione, fax (opzionale)

Specifiche Tecniche Brochures Manuali Immagini Driver Certificati Utilities

Specifiche Tecniche

general

Type Desktop Console Unit

Function Copy print scan optional: fax

Print technology Laser b/w

Original format max A3 from platen glass

Copy resolution 600 x 600 dpi

Greyscales 256

Paper feed (Universal cassettes amount) 2 x 500 sheet universal cassettes

Paper feed (1st cassette types) A6R-A4

Paper feed (2nd cassette types) A6R-SRA3

Paper feed (Multi-Bypass amount) 1 x 500 sheet 1 x 500 sheet

Paper feed (Multi-Bypass types) A6R-SRA3 Banner [305 x 1,219 mm]

Paper feed (print-only) SRA3 and banner

Paper output 500 sheet A4

System memory (Optional) 320 GB HDD

Functions Adjustable colour touch screen (10.1 inch) Adjustable colour touch screen (10.1 inch) duplex 1000 management codes skip blank pages motion sensor encryption/overwriting of hard disk data (Data Security Kit and Trusted Platform Module) secure boot and run time integrity check trusted platform modul (TPM) etc.

Print speed (A4, Simplex) B/W 50.0 b/w-pages/min.

Print speed (A3, Simplex) B/W 25.0 b/w-pages/min.

Copy speed (A4, Simplex) B/W 50.0 b/w-pages/min.

Copy speed (A3, Simplex) B/W 25.0 b/w-pages/min.

1st page (printing, b/w) 4.3 seconds

1st page (copying, b/w) 3.7 seconds

Paper weights (Universal cassette min) 52.0 g/m²

Paper weights (Universal cassette max) 300.0 g/m²

Paper weights (Multi-Bypass min) 52.0 g/m²

Paper weights (Multi-Bypass max) 300.0 g/m²

Paper weights (Duplex min) 64.0 g/m²

Paper weights (Duplex max) 256.0 g/m²

System memory (RAM) 4.0 GB

System memory (SSD) 128.0 GB

Continuous copying (min) 1.0

Continuous copying (max) 9999.0

Zoom (min) 25.0 %

Zoom (max) 400.0 %

Zoom (step) 1.0 %

scanSystem

Scan speed (Feeder 1, duplex, b/w) 274.0 DIN-A4-image pages/min. in 300 dpi

Scan speed (Feeder 1, simplex, b/w) 137.0 DIN-A4-image pages/min. in 300 dpi

Scan speed (Feeder 1, duplex, colour) 274.0 DIN-A4-image pages/min. in 300 dpi

Scan speed (Feeder 1, simplex, colour) 137.0 DIN-A4-image pages/min. in 300 dpi

Scan format max A3

File types TIFF JPEG PDF PDF/A high compression PDF encrypted PDF XPS OpenXPS

Interfaces 10/100/1000BaseTX

Network protocol TCP/IP

Optional feeder 1 DP-7170 document processor with simultaneous duplex scanning and multi-feed detection (A6R-A3, capacity: 320 sheet A4, paper weight 35-220 g/m²)

Operating systems Windows 7 Windows 8.1 Windows 10 Server 2008 Server 2008 R2 Server 2012 Server 2012 R2 Server 2016 Server 2019

Scan mode Photo text photo/text optimised for OCR

Functions Scan to SMB scan to e-mail scan to FTP scan to USB TWAIN scan WIA scan SMTP authentication LDAP

Scan type CCD colour and b/w

Scan resolution 200 dpi 300 dpi 400 dpi 600 dpi

printSystem

Print resolution (max) 1,200 x 1,200 dpi

Print resolution (min) 600 x 600 dpi

Emulations PCL6 (PCL 5e, XL) KPDL 3 (PostScript 3 compatible) XPS PRESCRIBE Ile

Functions USB direct printing PDF/XPS direct printing printing of e-mails private printing barcode printing SNMPv3 Mobile Print (Android, iOS)/Apple AirPrint

Operating systems Windows 7 Windows 8.1 Windows 10 Server 2008 Server 2008 R2 Server 2012 Server 2012 R2 Server 2016 Server 2019 Novell NetWare Linux Mac ex OS 10.9

Type Integrated within the system

Processor ARM A53 1,6GHz

Interfaces USB 3.0 USB 2.0 10/100/1000BaseTX USB host NFC SD-Card Slot

Print format A6R-SRA3

Network protocols TCP/IP Net BEUI

faxSystem

One touch dial 1000.0 numbers

Group dial 500.0 numbers

Modem speed 33.6 kbps

Abbreviated dial 2000.0 numbers

Fax memory 170.0 MB

Compatibility Super G3

Transmission speed 3 seconds or less using JBIG

Functions Network fax driver automatic redialling delayed transmission max 2 fax kits for parallel transmission and reception

Type Faxsystem 12

Operating systems Windows 7 Windows 8.1 Windows 10 Server 2008 Server 2008 R2 Server 2012 Server 2012 R2 Server 2016 Server 2019

Compression method JBIG MMR MR MH

Original format max A3

Fax resolution Standard (200 x 100 dpi) fine (200 x 200 dpi) super fine (200 x 400 dpi) ultra fine (400 x 400 dpi) 600 x 600 dpi

dimensionsWeight

Dimensions (height) 790.0 mm

Dimensions (width) 602.0 mm

Dimensions (depth) 665.0 mm

environment

Noise level (busy, b/w) 53.5 dB(A)

Noise level (standby) 31.9 dB(A)

Mains voltage 220/240 V

Safety GS/TÜV CE

Utility frequency 50/60 Hz

Power consumption (busy) 660.0 W

Power consumption (max) 1750.0 W

Power consumption (TEC) 0.6 kwh/week

Power consumption (standby) 45.0 W

Power consumption (sleep) 0.5 W

optional

Other options Scan extension kit (A) Internet fax kit (A) Card authentication kit (B) Keyboard holder 10 Banner guide 10 UG-33 ThinPrint® kit UG-34 Emulation option kit IB-50 Gigabit Ethernet card IB-51 WLAN card (IEEE802.11/b/g/n) IB-37 WLAN card (IEEE802.11a/b/g/n/ac) NK-7120 Numeric Keyboard (10 keys) DT-730(B) Document tray cabinet no. 81 HD-15 (320 GB HDD) HD-16 (1 TB HDD)

Finisher DF-7100 internal finisher (capacity: 500 sheet A4, stapling max 50 sheet A4) DF-7120 (capacity: 1,000 sheet A4, stapling max 50 sheet A4), PH-7120 hole punch unit for DF-7100 PH-7C hole punch unit for DF-7120/7140 PH-7C hole punch unit for DF-7120/7140 BF-730 brochure module for DF-7140 (max 20 sheet saddle stitching and folding A4/A3, tri-folding max X sheet A4) DF-7140 (capacity: 4,000 sheet A4, stapling max 65 sheet A4) MT- 730 (B) Multi Tray für DF-7140

Original platen cover Platen cover type E (if document processor is not installed)

Original feeder DP-7150 document processor with automatic reverse function (A6R-A3, capacity: 140 sheet A4, paper weight 35- 160 g/m²) DP-7140 document processor with automatic reverse function (A5R-A3, capacity: 50 sheet A4, paper weight 45-160 g/m²) DP-7160 document processor with simultaneous duplex scanning (A6R-A4, capacity: 320 sheet A4, paper weight 35-220 g/m²) DP-7170 document processor with simultaneous duplex scanning and multi-feed detection (A6R-A3, capacity: 320 sheet A4, paper weight 35-220 g/m²)

Job Separator JS-7100 (100 sheet, 52-300 g/m², A6R - SRA3) JS-7110 inner shift tray (250 sheet, 52-300 g/m², A6R - SRA3)

Paper feed PF-7140 (2 x 500 sheet universal cassettes [A5R-SRA3]) PF-7150 (2 x 1,500 sheet large capacity cassette [A4]) PF-7120 (3,000 sheet large capacity tray [A4], side deck)
