P-C2157wMFP

« Back

UTAX P-C2157wMFP

[P-C2157w-MFP]

scansione , fax , stampa , copia

Specifiche Tecniche Brochures Manuali Immagini Driver Certificati Utilities

Specifiche Tecniche

general

Type Desktop

Function scan fax print Copy

Print technology Laser colour and b/w

Original format max A4

Original feeder 50 sheet A4 (standard), min 140 x 182 mm, max 297 x 432 mm, 45-160 g/m² (simplex), 50-120 g/m² (duplex)

Copy resolution 600 x 600 dpi

Greyscales 256

Paper feed (Universal cassettes amount) 1 x 250 sheet

Paper feed (1st cassette types) A6R-A4

Paper feed (Multi-Bypass amount) 1 x 50 sheet

Paper feed (Multi-Bypass types) A6R-A4

Paper output 150 sheet A4

Functions duplex Apple AirPrint USB direct printing Wi-Fi Direct® quiet mode (half speed mode) skip blank pages 100 management codes N-up job reservation job programs trusted platform modul (TPM) Wi-Fi Mobile Print (Android/iOS) Google Cloud Print continuous scan ID card copy etc. printing of e-mails secure boot and run time integrity check Touch screen

Print speed (A4, Simplex) B/W 21.0 b/w-pages/min.

Copy speed (A4, Simplex) B/W 21.0 b/w-pages/min.

Print speed (A4, Duplex) B/W 10.5 b/w-pages/min.

Copy speed (A4, Duplex) B/W 10.5 b/w-pages/min.

Print speed (A4, Simplex) Colour 21.0 colour pages/min

Copy speed (A4, Simplex) Colour 21.0 colour pages/min

Print speed (A4, Duplex) Colour 10.5 colour pages/min

Copy speed (A4, Duplex) Colour 10.5 colour pages/min

1st page (printing, colour) 12.5 seconds

1st page (printing, b/w) 11.0 seconds

1st page (copying, colour) 12.0 seconds

1st page (copying, b/w) 10.0 seconds

Paper weights (Universal cassette min) 60.0 g/m²

Paper weights (Universal cassette max) 163.0 g/m²

Paper weights (Multi-Bypass min) 60.0 g/m²

Paper weights (Multi-Bypass max) 220.0 g/m²

Paper weights (Duplex min) 60.0 g/m²

Paper weights (Duplex max) 120.0 g/m²

System memory (RAM) 1.0 GB

System memory (RAM max) 1.0 GB

Continuous copying (min) 1.0

Continuous copying (max) 999.0

Zoom (min) 25.0 %

Zoom (max) 400.0 %

Zoom (step) 1.0 %

scanSystem

Scan speed (Feeder 1, simplex, b/w) 27.0 DIN-A4-image pages/min. in 300 dpi

Scan speed (Feeder 1, simplex, colour) 22.0 DIN-A4-image pages/min. in 300 dpi

Scan format max A4

File types JPEG XPS OpenXPS TIFF high compression and encrypted PDF PDF

Interfaces 10/100/1000BaseTX USB 2.0

Network protocol TCP/IP Net BEUI

Scan mode photo/text Photo optimised for OCR text

Functions LDAP scan to FTP Scan to SMB SMTP authentication WIA scan TWAIN scan scan to e-mail scan to USB

Scan type CIS colour and b/w

Scan resolution 200 dpi 300 dpi 400 dpi 600 dpi

printSystem

Print resolution (max) 1,200 x 1,200 dpi (reduced speed)

Print resolution (min) 600 x 600 dpi

Emulations KPDL 3 (PostScript 3 compatible) XPS PCL6 (PCL 5c, XL) Open XPS PRESCRIBE Ilc

Functions duplex USB direct printing Wi-Fi Direct® Mobile Print (Android/iOS) Apple AirPrint Mopria Google Cloud Print private printing printing of e-mails

Operating systems Windows 10 Windows 8 Server 2012 R2 Server 2008 R2 Server 2016 Windows 8.1 Mac ex OS 10.9 Server 2019 Linux

Type Integrated within the system

Interfaces 10/100/1000BaseTX USB 2.0 USB host Wi-Fi SD-Card Slot

Print format A6R-A4

Network protocols TCP/IP Net BEUI

faxSystem

One touch dial 100.0 numbers

Group dial 50.0 numbers

Modem speed 33.6 kbps

Abbreviated dial 200.0 numbers

Fax memory 6.75 MB

Compatibility Super G3

Transmission speed 3 seconds or less using JBIG

Functions delayed transmission automatic redialling Network fax driver

Type Integrated within the system

Compression method MH MR JBIG MMR

Original format max A4

Fax resolution super fine (200 x 400 dpi) Standard (200 x 100 dpi) ultra fine (400 x 400 dpi) fine (200 x 200 dpi)

dimensionsWeight

Dimensions (height) 457.0 mm

Dimensions (width) 417.0 mm

Dimensions (depth) 416.0 mm

environment

Noise level (busy, b/w) 45.2 dB(A)

Noise level (busy, colour) 45.8 dB(A)

Mains voltage 220/240 V

Safety CE GS/TÜV

Utility frequency 50/60 Hz

Power consumption (busy) 345.0 W

Power consumption (max) 1066.0 W

Power consumption (TEC) 0.2 kwh/week

Power consumption (standby) 41.0 W

Power consumption (sleep) 0.4 W

optional

Other options UG-33 ThinPrint® kit cabinet no. 77 Card authentication kit (B)

Paper feed max 1 x PF-5110 (250 sheet universal cassettes [A6R-A4, 60-163 g/m²])
