UTAX 3263i
[3263i]Multifunzione copia/stampa/Scanner
Specifiche Tecniche
Type |
Desktop
|
|
Function |
optional: fax
scan
print
Copy
|
|
Print technology |
Laser b/w
|
|
Original format |
max A3 from platen glass
|
|
Print speed (A4, Simplex) B/W |
32
|
|
Copy speed (A4, Simplex) B/W |
32
|
|
Print speed (A4, Duplex) B/W |
17
|
|
Copy speed (A4, Duplex) B/W |
17
|
|
1st page (printing, b/w) |
4.9
|
|
1st page (copying, b/w) |
4.3
|
|
Warm-up time |
18
|
|
Copy resolution |
600 x 600 dpi
|
|
Greyscales |
256
|
|
Paper feed (Universal cassettes amount) |
2 x 500 sheet universal cassettes
|
|
Paper feed (1st cassette types) |
A5R-A3
|
|
Paper feed (2nd cassette types) |
A5R-A3
|
|
Paper feed (Multi-Bypass amount) |
100 sheet multi-bypass (A6R-A3)
|
|
Paper feed (Multi-Bypass types) |
A6R-A3
|
|
Paper weights (Universal cassette min) |
60
|
|
Paper weights (Universal cassette max) |
163
|
|
Paper weights (Multi-Bypass min) |
45
|
|
Paper weights (Multi-Bypass max) |
256
|
|
Paper weights (Duplex min) |
60
|
|
Paper weights (Duplex max) |
163
|
|
Job Separator |
50 sheet A4 (standard)
|
|
System memory (RAM) |
4
|
|
System memory (RAM max) |
4
|
|
System memory (SSD) |
32
|
|
Continuous copying (min) |
1
|
|
Continuous copying (max) |
9999
|
|
Zoom (min) |
25
|
|
Zoom (max) |
400
|
|
Zoom (step) |
1
|
|
Functions |
Adjustable colour touch screen (10.1 inch)
1000 management codes
skip blank pages
encryption/overwriting of hard disk data (Data Security Kit and Trusted Platform Module)
secure boot and run time integrity check
trusted platform modul (TPM)
duplex
etc.
|
|
Dimensions (height) |
683
|
|
Dimensions (width) |
594
|
|
Dimensions (depth) |
696
|
|
Weight |
59
|
|
Mains voltage |
220/240 V
|
|
Utility frequency |
50/60 Hz
|
|
Power consumption (max) |
1620
|
|
Power consumption (busy) |
510
|
|
Power consumption (standby) |
100
|
|
Power consumption (sleep) |
0.5
|
|
Power consumption (TEC) |
0.4
|
|
Noise level (busy, b/w) |
48
|
|
Noise level (standby) |
31.4
|
|
Safety |
CE
GS/TÜV
|
|
Type |
Integrated within the system
|
|
Print format |
A6R-A3
|
|
Print resolution (min) |
600 x 600 dpi
|
|
Print resolution (max) |
1,200 x 1,200 dpi
|
|
Interfaces |
10/100/1000BaseTX
USB host
USB 3.0
SD-Card Slot
|
|
Network protocols |
TCP/IP
Net BEUI
|
|
Operating systems |
Windows 8.1
Windows 10
Server 2012 R2
Server 2016
Server 2019
Linux
Mac ex OS 10.9
|
|
Emulations |
KPDL 3 (PostScript 3 compatible)
XPS
PRESCRIBE Ile
PCL6 (PCL 5c, XL)
PDF
|
|
Functions |
USB direct printing
Apple AirPrint
NFC
private printing
barcode printing
SNMPv3
PDF direct printing
Wi-Fi
etc.
|
|
Scan type |
CCD colour and b/w
|
|
Scan format |
max A3
|
|
Scan resolution |
300 dpi
200 dpi
400 dpi
600 dpi
|
|
Scan mode |
text
photo/text
optimised for OCR
|
|
File types |
TIFF
JPEG
XPS
PDF/A
PDF/A-1a
PDF/A-1b
PDF/A-2a
PDF/A-2b
high compression and encrypted PDF
OpenXPS
|
|
Interfaces |
10/100/1000BaseTX
|
|
Network protocol |
TCP/IP
|
|
Operating systems |
Windows 10
Server 2012 R2
Server 2016
Windows 8.1
Server 2019
|
|
Functions |
scan to FTP
Scan to SMB
SMTP authentication
WIA scan
TWAIN scan
scan to USB
scan to e-mail
|
|
Type |
Faxsystem 12
|
|
Compatibility |
Super G3
|
|
Original format |
max A3
|
|
Modem speed |
33.6
|
|
Transmission speed |
3 seconds or less using JBIG
|
|
Compression method |
JBIG
MMR
MH
MR
|
|
Fax resolution |
Standard (200 x 100 dpi)
fine (200 x 200 dpi)
super fine (200 x 400 dpi)
ultra fine (400 x 400 dpi)
600 x 600 dpi
|
|
Fax memory |
170
|
|
Abbreviated dial |
2000
|
|
One touch dial |
1000
|
|
Group dial |
500
|
|
Operating systems |
Windows 8.1
Windows 10
Server 2012 R2
Server 2016
Server 2019
|
|
Functions |
delayed transmission
max 2 fax kits for parallel transmission and reception
automatic redialling
Network fax driver
|
|
Original feeder |
DP-7140 document processor with automatic reverse function (A5R-A3, capacity: 50 sheet A4, paper weight 45-160 g/m²)
DP-7150 document processor with automatic reverse function (A6R-A3, capacity: 140 sheet A4, paper weight 35- 160 g/m²)
DP-7170 document processor with simultaneous duplex scanning and multi-feed detection (A6R-A3, capacity: 320 sheet A4, paper weight 35-220 g/m²)
DP-7160 document processor with simultaneous duplex scanning (A6R-A4, capacity: 320 sheet A4, paper weight 35-220 g/m²)
|
|
Original platen cover |
Platen cover type E (if document processor is not installed)
|
|
Finisher |
DF-7120 (capacity: 1,000 sheet A4, stapling max 50 sheet A4),
DF-791 (capacity: 3,000 sheet A4, stapling max 65 sheet A4)
PH-7C hole punch unit for DF-7120/DF-791
|
|
Paper feed |
PF-810 (2 x 1,500 sheet large capacity cassette [A4])
PF-791 (2 x 500 sheet universal cassettes [A5R-A3])
|
|
Other options |
Scan extension kit (A)
Card authentication kit (B)
HD-15 (320 GB HDD)
HD-16 (1 TB HDD)
NK-7120 Numeric Keyboard (10 keys)
Keyboard holder 10
Internet fax kit (A)
IB-50 Gigabit Ethernet card
IB-51 WLAN card (IEEE802.11/b/g/n)
IB-37 WLAN card (IEEE802.11a/b/g/n/ac)
cabinet no. 70
Banner guide (A)
DT-730(B) Document tray
UG-34 Emulation option kit
UG-33 ThinPrint® kit
|
